5600 Series

  • Record

The 5600 Series Sliding Door System provides silent microprocessor-driven gear reduction belt drive operation for years of dependable service. This Swiss and American-designed sliding door has the latest in electronic assembly and software programming and comes with a lifetime warranty for the door track system. The Record 5600 Series sliding door available in all ANSI configurations, and can be applied to all types of specialty applications.

Offering a wide breadth of configurations and functions, the record 5600 series assures the architect and building owner a wide array of capabilities providing the safest, most secure, and attractive entranceway available.

Different operating modes

  • Automatic mode with full opening width
  • Automatic mode with reduced opening width
  • Automatic mode in one-way (exit only) for traffic control
  • Adjustable reduced opening mode
  • Continuously open: door opens and remains in open position; either full open or reduced opening width
  • Off mode: door can be moved by hand

Safety Functions

  • Safety sensors (self-monitoring holding beams) in the clear opening of the door prevent the door from shutting if persons or objects are in the detection zone.
  • Safety automatic reversing mechanism: if the door leaves are inhibited when closing, they are immediately re-opened (automatic reverse 2-step adjustable). If the door leaves are hindered when opening, they are immediately stopped.
  • The position of the obstacle is stored and will be slowly approached during the next door movement.
  • Even in the case of power failure, the emergency fail close or the emergency opening is assured by the optional emergency power options.
  • Sidelite protection - Additional sensors located above the opening path of the door will slow the opening if a person or object will inhibit the door opening normally.

Options

  • Choose the Record 5600 series when desiring to automate wood, hollow metal or other door types and still get the reliability, durability, and silence of the record 5100 series.

Find a Dealer
  • Product Brochures
    Specs
    Drawings (pdf)
    Model(PDF, 73 KB)
    C:\Users\202-bjg\Desktop\WoodSwayGuideBO_Prep Model (1)(PDF, 76 KB)
    SO Wood Panel(PDF, 124 KB)
    DBO_SXAssemblies.cdr(PDF, 124 KB)
    D:\Mikes\5100\Doors-By-Others Prep.DWG Model (1)(PDF, 203 KB)
    Model(PDF, 72 KB)
    Model(PDF, 73 KB)
    C:\Documents and Settings\202-dph\My Documents\EngDwgs\DoorByOthers\51-2.83DBO Model (1)(PDF, 147 KB)
